DESCRIPTION:
Item No: Specification Conductor Pairs Packaging Length
S0001 UTP Cat6 23AWG 0.575 4 RB 305m
S0002 UTP Cat6 24AWG 7x0.20 4 RB 305m
S0003 UTP Cat6 26AWG 7x0.16 4 RB 305m
S0004 FTP Cat6 24AWG 7x0.20 4 RB 305m
S0005 FTP Cat6 26AWG 7x0.16 4 RB 305m
RB=Reel Pull-out Box

Frequency

MHZ		 Impedance

ohms		 RL

dB		 Attenuation

dB		 Next Near End Crosstalk

dB		 Power Sum Next

dB		 Attenuation To Crosstalk Ratio

dB		 Nominal Velocity Differential Phase Delay

ns		 Power Sum Atten-uation To Crosstalk Ratio ACR/NEXT ps

dB		 Equal Level Far End Crosstalk (ELEFEXT)

dB		 Power Sum Level Far End Crosstalk(Ps ELFEXT)

dB
0.772 100+-15 19.44 1.84 76.0 74.0 74.1 0.65 20.0 72.1 70.0 67.0
1.0 20.00 2.04 74.3 72.3 72.3 70.3 67.8 64.8
4.0 23.01 3.81 65.3 63.3 61.5 59.5 55.8 52.8
8.0 24.52 5.35 60.8 58.8 55.4 53.4 49.7 46.7
10.0 25.00 5.99 59.3 57.3 53.3 51.3 47.8 44.8
16.0 25.00 7.60 56.2 54.2 48.6 46.6 43.7 40.7
20.0 25.00 8.52 54.8 52.8 46.3 44.3 41.8 38.8
25.0 24.32 8.57 53.3 51.3 43.8 41.8 39.8 36.8
31.25 23.64 10.74 51.9 49.9 41.1 39.1 37.9 34.9
62.5 21.54 15.48 47.4 45.4 31.9 29.9 31.9 28.9
100.0 20.10 19.92 44.3 42.3 24.4 22.4 27.8 24.8
125.0 19.42 22.49 42.8 40.8 20.4 18.4 25.9 22.9
200.0 18.00 29.15 39.8 37.8 10.6 8.6 21.8 18.8
250.0 17.32 33.04 38.3 36.3 5.3 3.3 19.8 16.8
